Model	Cardiac Ambulance BS – III	Cardiac Ambulance BS-IV
Engine & Displacement	SLT3 & Numeral , 3455 cc	SLT4 & Numeral , 3455 cc
Type	In line 4-Cylinder Direct Injection	In line 4-Cylinder Common Rail Direct Injection
	Diesel Turbo Charger with Intercooler
Max.Engine Output	75 Kw @3000 rpm	75 Kw @2800 rpm
Max. Torque	270Nm@1750-2000 rpm	296Nm @ 1500 rpm
Clutch	Single plate Diaphragm Type , Dia. 260mm
Gear Box	Synchromesh Manual 5-Forward and 1-Reverse
Steering	Mechanical /Power Steering (Optional)
Brakes	Hydraulic Vaccume assisted/ Air brake (optional)
Suspension	Semi Elliptical Type Multi Leaf Spring
Min. Ground clearance	206
Wheel & Tyres	7.50” X 16” - 16 PR	8.25” X 16” - 16 PR
No of Tyres	6 + 1	4+1
Wheelbase (mm)	3335	3335
Min. Turning Circle Diameter (m)	6.4	6.4
Front Axle Weight (kg)	2360	2400
Rear Axle Weight (kg)	4080	3590
Max. Permissible GVW (kg)	6440	5990
Fuel Capacity (lts)	90	90
Overall Length	5479	5479
Overall Width	2100	2100
Overall Height	2725	2725

Features

Doctor's seat

Attendant seat with storage space

Complete FRP Interior

First Aid Kit

Oxygen supply system with two nos outlets

Inverter 800 VA

Anti acidic stain free floor

Rear flood light

Fire extinguisher

Wash Basin

Foldable stretcher cum trolley

PA System

Provision for drinking water

Bar light and side blinkers

Tube and focus light in patient compartment on AC & DC supply

Electrical provision for AC/DC Supply (220V/12V)

Note : As per our policy of continuous improvement, specifications may change without notice.
