Model	Supreme BS – III	Supreme BS-IV
Engine & Displacement	SLT3 & Numeral , 3455 cc	SLT4 & Numeral , 3455 cc
Type	In line 4-Cylinder Direct Injection	In line 4-Cylinder Common Rail Direct Injection
Diesel Turbo Charger with Intercooler
Max.Engine Output	75 Kw @3000 rpm	75 Kw @2800 rpm
Max. Torque	270Nm@1750-2000 rpm	296Nm @ 1500 rpm
Clutch	Single plate Diaphragm Type , Dia. 260mm
Gear Box	Synchromesh Manual 5-Forward and 1-Reverse
Steering	Mechanical /Power Steering (Optional)
Brakes	Hydraulic Vaccume assisted
Suspension	Semi Elliptical Type Multi Leaf Spring
Wheel & Tyres	7.50” X 16” - 16 PR
No of Tyres	6 + 1
Wheelbase (mm)	2815	3335	3940	4760
Min. Turning Circle Diameter (m)	5.5	6.4	7.6	9.4
Front Axle Weight (kg)	2800	2800	2800	2800
Rear Axle Weight (kg)	5200	5200	5200	5200
Kerb Weight (kg)	2750	2800	2900	3000
Max. Permissible GVW (kg)	8000
Cargo Box Dimensions (LXBXH) (mm)
Variants
Cab Halfdeck Loadbody	3740X2080X1030	4260X2080X570	5240X2080X570	6610X2080X570
Cab Semideck Loadbody	3740X2080X1030	4260X2080X1030	5240X2080X1030	Not Available
Cab Highdeck Loadbody	3740X2080X1695	4260X2080X1695	5240X2080X1695	Not Available
Cabin Chasis	Available

Features

Available in BS-III & BS-IV versions

Powerful engine, higher pickup, higher torque at lower RPM, Gradeability and fuel efficient

Heavy duty gearbox and bigger clutch – longer life

Steering with variable gear ratio – less driver fatigue

Roof ventilation for better comfort

Ready availability of spares at reasonable price

Box type chasis with tubular cross members- carry more load, provide better strength and rigidity

Note : As per our policy of continuous improvement, specifications may change without notice.
